Main Features :
Certification：CE,ISO9001
Discharge Way：Bottom Valve
Type：Normal Type
Material：SS304,SS316,Ceramic,PU Or Carbon Steel Can Be Choose
Speed：Controlled By Frequency Converter Or Fixed
Polish：Mirror Polish Or Non-Polish
Main Features :
Certification：CE,ISO9001
Discharge Way：Bottom Valve
Type：Normal Type
Material：SS304,SS316,Ceramic,PU Or Carbon Steel Can Be Choose
Speed：Controlled By Frequency Converter Or Fixed
Polish：Mirror Polish Or Non-Polish
▪ The ball mill can be horizontal ball mill and vertical ball mill.
▪ The grinding ball materials of the ball mill include:
Ceramics,stainless steel,carbon steel etc.
▪ The grinding cylinder material can be processed into:
Carbon steel,stainless steel, ceramic lined,wear-resistant polyurethane lined etc.
The ball mill is used for ball milling and crushing fluid,semi fluid,and powder material.
Ball mill are widely used in industries such as coatings,paints,rubber,abrasives, ceramics,minerals,coal powder,metal powder,talc powder,carbon black,ink,dyes,and food.
Model | Power(KW) | Speed(RPM) | Material Capacity(L) | Ball Capacity(L) | Weight(Kg) |
50L | 2.2 | 55 | 20 | 25 | 100 |
100L | 3 | 50 | 40 | 50 | 220 |
200L | 4 | 50 | 90 | 100 | 360 |
300L | 4 | 50 | 130 | 150 | 510 |
500L | 5.5 | 45 | 220 | 225 | 780 |
1000L | 11 | 40 | 450 | 500 | 1060 |
1500L | 15 | 35 | 700 | 750 | 1600 |
2000L | 18.5 | 35 | 900 | 1000 | 2200 |
