Main Features :
Certification：CE,ISO9001
Discharge Way：Bottom Valve
Funcation：Heating,Cooling,Vacuum,Pressure
Type：Normal Type,Pressure Type,Vacuum Type
Material：SS304,SS316 Or Carbon Steel Can Be Choose
Speed：Controlled By Frequency Converter Or Fixed
Polish：Mirror Polish Or Non-Polish
Blade：Disc Shape,Paddle Shape,Propeller Or Customized
▪ Under the action of high-speed rotation, the dispersion disc will stir,dissolve and disperse the liquid and liquid-solid material at high speed to complete the process of solid-liquid dispersion, wetting, depolymerization and stabilization. Speed regulation 0-1450RPM, medium speed for stirring dissolution, high speed for dispersion and homogenization.
▪ There are single shaft high speed disperser and two shafts high speed disperser,heating,cooling,vacuum and other functions can be added as requirement.
▪ The high speed disperser widely used for paint,dye,ink,pigment,paper,cosmetics, food, resin, adhesive, emulsion, medicine, petroleum, pesticides etc.
▪ High Speed Disperser As Structure:
1.Single Shaft High Speed Disperser
2.Dual Shaft High Speed Disperser
▪ High Speed Disperser As Function:
1.Heating Type
2.Cooling Type
3.Vacuum Type
4.Normal Temperature Type
5.Pressure Type
▪ High Speed Disperser As Lift Way:
1.Hydraulic Lifting
2.Mechanical Lifting
Model | Lab | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 |
Power(KW) | 0.4-2.2 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 |
Suitable Capacity(L) | 2-50 | 100-200 | 200-300 | 300-500 | 500-700 | 700-800 | 800-1000 | 1000-1200 | 1200-1400 | 1400-1600 | 1600-2000 |
Speed(RPM) | 0-1450 | ||||||||||
Lift Way | Manual | Hydraulic Or Mechanical | |||||||||
Shaft | Single | Single Or Double | |||||||||
Heating Way | NO | Electrical Heater In Jacket;Cycle Hot Water/Oil/Steam In Jacket | |||||||||
Cooling Way | NO | Cycle Cold Water In Jacket | |||||||||
Vacuum | NO | -0.098Mpa | |||||||||
Lift Height(mm) | 400 | 800-1300 | |||||||||
